QINKPFPV F722+65A Combo (FC+ESC) for Racing Drones

F722 Flight Controller + 65A ESC Combo for FPV Drones

Designed for FPV drone applications, this QINKPFPV F722 flight controller and 65A ESC combo delivers responsive control performance, stable power handling, and reliable system integration for multi-rotor drone builds. It is suitable for FPV platforms that require efficient flight control, broad protocol support, and dependable power management.

The F722 flight controller is equipped with advanced onboard components including an ICM 42688-P gyroscope, 16MB blackbox, barometer, and multiple UART ports for flexible peripheral integration. Paired with a 65A 32-bit ESC supporting mainstream control protocols, this combo provides smooth motor response and stable operation across demanding FPV drone applications.

Key Features - Flight Controller

• F722 flight controller designed for stable and responsive FPV control
• STM32F722 main controller for reliable processing performance
• ICM 42688-P gyroscope for precise flight data handling
• 16MB blackbox for flight data recording and tuning support
• Integrated barometer for expanded flight control functionality
• 5V and 10V BEC outputs for flexible power supply options
• 10V BEC ON/OFF function for convenient system configuration
• 6 UART serial ports for flexible peripheral connectivity
• Supports 3-6S LiPo batteries

Key Features - ESC

• 65A continuous current rating for reliable power delivery
• 80A instant current handling
• 32-bit ESC architecture for smooth and efficient motor control
• Supports 3-6S LiPo batteries
• Compatible with mainstream protocols including Oneshot125, Oneshot42, Multishot, and DShot 300/600/1200
• Designed for stable response and dependable performance in FPV drone systems

Technical Specifications

• Firmware Target: F722
• Main Control: STM32F722
• Gyroscope: ICM 42688-P
• Blackbox: 16MB
• Barometer: Yes
• BEC Output: 5V, 10V
• 10V BEC Function: ON/OFF
• UART Serial Ports: 6
• Input Voltage: 3-6S LiPo
• ESC Continuous Current: 65A
• ESC Instant Current: 80A
• ESC Firmware: 32-bit
• Supported Protocols: Oneshot125 / Oneshot42 / Multishot / DShot 300 / 600 / 1200
• Flight Controller Size: 38 × 38mm
• Flight Controller Mounting Holes: 30.5 × 30.5mm (M3)
• ESC Size: 56.2 × 57.0mm
• ESC Mounting Holes: 30.5 × 30.5mm (M3)

Package Includes

• 1 × QINKPFPV F722 Flight Controller
• 1 × QINKPFPV 65A Electronic Speed Controller
• M3 Mounting Screws
• 1 × English User Manual
