QINKOFPV 4715-450KV"BOLT

Name: QINKOFPV 4715-450KV"BOLT
Brand: QINKO FPV
SKU: QK-ROCKET-3200
Price: 35.00 USD
Availability: InStock

Inquiry Now Send Message

View details

Description

Overview Designed for 15-inch heavy-payload FPV drone frames and professional commercial platforms, the QINKOFPV 4715-450KV brushless motor delivers strong and stable power output for demanding industrial flight applications. Built to provide reliable thrust, smooth power delivery, and consistent thermal performance, it is a highly practical and dependable propulsion choice for enterprise FPV drone builds.

🚀 Core Features & Advantages

Heavy-Lift Propulsion: Engineered specifically for 15-inch propeller configurations, delivering an outstanding maximum pull force of up to 3200g per motor for heavy-payload stability.
Efficient Power Delivery: Rated for 840W maximum power output and optimized for 24V (6S LiPo) configurations, ensuring your commercial drones maintain stable thrust and efficient energy use.
Robust Thermal Management: Features a durable aluminum alloy housing and high-efficiency 18AWG copper windings, guaranteeing excellent heat dissipation during extended mission flights.
Precision Engineering: Designed with a 12N14P slot pole configuration and a sturdy 5.0mm shaft to withstand intense structural loads, maintaining perfectly smooth rotational consistency.

📊 Technical Specifications

Model: QINKOFPV 4715-450KV
KV Value: 450KV
Compatible Frame Size: 15-Inch FPV Drone
Operating Voltage: 24V (6S LiPo)
Max Continuous Power: 840W
Max Current: 35A
Max Thrust (Pull): 3200g
No-load Current: 0.70A / 10V
Slot Pole Configuration: 12N14P
Shaft Diameter: 5.0mm
Motor Dimensions: 52.0mm × 47.0mm
Mounting Hole Spacing: 25.4mm × 25.4mm (M3×4)
Motor Cable: 18AWG / 200mm
Weight: 234.8g (including cables)

🤝 B2B Wholesale & OEM Supply As a dedicated manufacturing facility, QINKOFPV strictly serves B2B clients, regional distributors, and enterprise drone manufacturers.

Baseline: B2B Only | Minimum Order Quantity (MOQ): 100 Units.
OEM/White-Label: We offer full customization and non-disclosure agreement (NDA) compliance to protect your commercial project margins.
Bulk Pricing: Contact our B2B sales team directly for tiered wholesale discounts and industrial integration support.
