Overview Designed for industrial and commercial FPV drone applications, the QINKOFPV FO-0.25-1 G657A2 Fiber Optic Cable Reel (1KM) provides exceptionally stable signal transmission, ultra-low attenuation, and reliable performance in complex high-interference industrial environments. Engineered specifically for high-altitude communication operations that have stringent requirements on payload weight and volume, this ABS-housed drum ensures continuous, secure data transmission for demanding commercial surveying and long-distance inspection missions.
🚀 Core Features & Advantages
-
Ultra-Fine & Lightweight Design: Features an ultra-fine 0.25mm outer diameter and an invisible transparent tight buffer. The entire 1KM reel, including the ABS shell, weighs only 0.25kg, maximizing your drone's effective flight time and payload capacity.
-
High Bending Resistance: Built with premium G.657A2 fiber, offering outstanding flexibility and mechanical reliability to resist harsh bending during high-speed aerial deployments.
-
Ultra-Low Attenuation: Delivers exceptional optical performance with typical attenuation as low as 0.185 dB/km at 1550nm, ensuring stable long-distance signal integrity without loss.
-
Industrial-Grade Durability: Protected by a high-strength resin coating and a rugged ABS drum shell, capable of withstanding extreme operating temperatures from -40°C to +85°C.
-
Standardized Integration: Comes equipped with standard FC/FC optical interfaces for rapid and seamless connection to enterprise FPV communication systems.
📊 Technical Specifications
-
Product Model: FO-0.25-1 (1KM Version)
-
Fiber Type: G.657A2 (High Bending Resistance)
-
Standard Fiber Length: 1,000 m (1KM)
-
Jacket Material: High-Strength Resin
-
Drum Shell Material: ABS
-
Optical Interface: FC / FC
-
Fiber Optic Outer Diameter: 0.25 mm ± 0.01
-
Tight Buffer Color: Invisible Transparent
-
Fiber Tensile Strength: 60N
-
Unit Weight (Fiber Only): 80 g/km
-
Total Weight (Including Fiber & Drum): 0.25 KG
-
Product Dimensions: 75mm × 205mm
-
Operating Temperature: -40°C to +85°C
📡 Fiber Attenuation Parameters
-
1310nm: Specification ≤ 0.35 dB/km | Typical: 0.329 dB/km
-
1550nm: Specification ≤ 0.25 dB/km | Typical: 0.185 dB/km
📦 Package Includes
- 1 × QINKOFPV FO-0.25-1 Fiber Optic Cable Reel (1KM)
- 1 × FC/FC Optical Connector Accessories
🤝 B2B Wholesale & OEM Supply As a dedicated manufacturing facility, QINKOFPV strictly serves B2B clients, regional distributors, and enterprise drone manufacturers.
-
Baseline: B2B Only | Minimum Order Quantity (MOQ): 100 Units.
-
OEM/White-Label: We offer full customization and non-disclosure agreement (NDA) compliance to protect your commercial project margins.
-
Bulk Pricing: Contact our B2B sales team directly for tiered wholesale discounts and industrial integration support.
