Overview
The QINKOFPV 10-Inch Heavy Lift FPV Drone is an industrial-grade, bind-and-fly (BNF) platform meticulously engineered for heavy payloads, cinematic camera rigs, and rigorous commercial applications. Featuring a robust Wide X-Type frame exclusively constructed from premium T300 carbon fiber and an ultra-powerful propulsion system, it delivers unmatched stability and thrust for the most demanding professional missions.

🚀 Core Flight Performance

  • Massive Payload Capacity: Designed to comfortably carry a 3 to 4 kilograms payload. Achieve approximately 20 minutes of loaded flight time, or an impressive 40 minutes of cruising without a payload (optimized for a 10000 mAh battery).
  • Long Range & High Speed: Capable of reaching top speeds of 140 kilometers per hour. It offers an extensive operational flying distance of 5 to 10 kilometers, and can operate at maximum altitudes up to 6000 meters.
  • Industrial-Grade Frame: Built on a 420 millimeters wheelbase Wide X-Type frame. It features ultra-thick 7.0 millimeters carbon fiber arms and 3.0 millimeters top/bottom plates, ensuring maximum rigidity under heavy loads.

🛠️ Premium Electronic Components

  • Heavy-Duty Propulsion: Powered by massive 3115 class 900KV motors, each delivering up to 3950 grams of maximum thrust, paired with efficient 10-inch tri-blade fiberglass nylon propellers.
  • Reliable Flight Stack: Equipped with a high-performance F405 Flight Controller (STM32-F405 MCU) and a heavy-duty 60 Amps 4-in-1 ESC to safely handle sustained high currents.
  • Night-Vision Ready FPV System: Features an ultra-clear 1800-TVL 1/2.4 CMOS camera with an incredible F1.0 aperture (0.0001 Lux) for low-light operations, coupled with an extreme-range 5.8G VTX adjustable up to 3000 milliWatts.
  • Unshakeable Control Link: Pre-installed with an ELRS 915 MegaHertz receiver to guarantee ultra-low latency and secure long-range connectivity.

📊 Detailed Specifications

Frame Wheelbase 420 millimeters (Wide X-Type)
Motors 3115 - 900KV
Maximum Thrust 3950 grams per motor
Flight Controller F405 4 to 8S (Type C USB)
ESC 60 Amps 4-in-1 (70 Amps Burst)
Camera 1800-TVL Extreme Low Light (F1.0)
Video Transmitter Adjustable up to 3000 milliWatts
Receiver ELRS 915 MegaHertz
Recommended Battery 10000 mAh Li-Po / Li-ion (Not Included)

🤝 B2B Wholesale & OEM/ODM Solutions

Are you looking for reliable, heavy-lift FPV solutions for your commercial projects or distribution network? We specialize in empowering B2B clients, wholesalers, and industrial drone integrators.

  • Bulk Pricing: Competitive tier-based discounts for distributors and importers.
  • Customization (OEM): We offer tailored configurations, custom branding, payload integrations, and specialized tuning to meet your exact project requirements.

👉 Ready to scale your drone operations?
Click the WhatsApp button below or use our contact form to reach our B2B sales team instantly for bulk quotes, custom specifications, and shipping details!

Product specifications table
Specification name Specification Value
Battery size Unknown
Battery type Standalone (not-included)
Color pattern Black
Translation missing: en.metafields.shopify.drone-features Long battery life, Night vision
Item condition New
