QINKOFPV 13-Inch Ultra Heavy Lift FPV Drone BNF (6 to 8 KG Payload)

Name: QINKOFPV 13-Inch Ultra Heavy Lift FPV Drone BNF (6 to 8 KG Payload)
Brand: QINKO FPV
Availability: InStock

Inquiry Now Send Message

View details

Description

Overview

The QINKOFPV 13-Inch Ultra Heavy Lift FPV Drone is an elite-tier, bind-and-fly (BNF) aerial platform designed for top-end cinematic productions, massive industrial payloads, and specialized commercial operations. Built on a highly rigid Positive X configuration frame and driven by a monstrous propulsion system, it delivers unparalleled lifting capability without sacrificing flight stability and precision. The frame is exclusively constructed from premium T300 carbon fiber to ensure maximum durability and rigidity under extreme payloads.

🚀 Core Flight Performance

Extreme Payload Capacity: Engineered to effortlessly carry a massive 6 to 8 kilograms payload. It achieves up to 20 minutes of flight time fully loaded, or a remarkable 40 minutes of cruising time without a payload (optimized for a 12000 mAh battery).
Long Range & Speed: Capable of reaching maximum speeds of 130 kilometers per hour. It provides a vast operational flying distance of 6 to 8 kilometers and can perform at maximum altitudes up to 6000 meters.
Ultra-Rigid Industrial Frame: Constructed with a 593 millimeters wheelbase Positive X frame. It utilizes thick carbon fiber plates (4.0 millimeters bottom and middle plates) and features dedicated internal clearances to house complex electronics and heavy payloads securely.

🛠️ Premium Electronic Components

Monstrous Propulsion: Powered by huge 4315 class 510KV motors, with each motor capable of generating an incredible 7800 grams of maximum thrust, perfectly paired with 13-inch tri-blade fiberglass nylon propellers.
Industrial Flight Stack: Controlled by a reliable F405 Flight Controller (STM32-F405 MCU) and heavily supported by a high-capacity 80 Amps 4-in-1 ESC (capable of 100 Amps burst currents) running the FPV-32 firmware.
Advanced Vision & Transmission: Equipped with an 1800-TVL 1/2.4 CMOS night-vision ready camera (0.0001 Lux rating) and a long-range 5.8G VTX, fully adjustable up to an extreme 3000 milliWatts output power.
Secure Control Link: Pre-installed with an ELRS 915 MegaHertz receiver, ensuring a stable, ultra-low latency connection over long distances.

📊 Detailed Specifications

Frame Wheelbase	593 millimeters (Positive X Configuration)
Motors	4315 - 510KV
Maximum Thrust	7800 grams per motor
Flight Controller	F405 4 to 8S (Type C USB)
ESC	80 Amps 4-in-1 (100 Amps Burst)
Propellers	13 by 8 by 3 Tri-blade
Camera	1800-TVL Extreme Low Light (F1.0)
Video Transmitter	Adjustable up to 3000 milliWatts
Receiver	ELRS 915 MegaHertz
Recommended Battery	12000 mAh Li-Po / Li-ion (Not Included)
